I. Product Description:
impulse voltage generator is used for impulse voltage test of lightning impulse voltage full wave , lightning impulse voltage chopped wave and operation impulse voltage wave which apply to electrical equipment ect. Multiple waveform impulse voltage generator can produce eight kinds of waveforms of standard lightning wave, operation wave, lightning chopped wave, oscillating lightning wave, oscillating operation wave, line insulator steep wave, composite insulator steep wave, transformer induction operation wave. The technology index accords with national standard and IEC standard, is in the leading position at home and has reached an advanced level in the world.
II. Product Features:
- Complete sets, full voltage classes.
- Small loop inductance, take the band elimination filter measures, still produce standard impulse wave in the large-capacity load , large load capacity, high voltage utilization, convenient to adjust wave.
- Simple operation, excellent synchronization performance, reliable action.
- Use constant current charging technology, high automation, strong anti-interference performance.
- Use digital measurement and analysis system and computer on line processing system for impulse test data, greatly improve the test technology and efficiency.
III. Product Parameters:
| Charging voltage |
Setting range |
0 ~ 100kV |
| Scope of work |
20 ~ 100kV |
| Setting deviation |
≤ ±1% |
| Don't stability |
≤ ±1% |
| Setting distinguish |
0.1kV |
| Charging time |
Setting range |
30~180s |
| Setting distinguish |
1s |
| Alarm time delay |
2s |
| Number of pressure |
Setting range |
1~999 |
| Protection setting |
Overcurrent protection value |
Can be set |
| Overcurrent protection value |
Can be set |
| Dynamic charge protection |
Can be set |
| Trigger pulse |
More than 15kV, rising time less than 100ns, polarity can be switched |
| Output impact stability |
More than 99% |
About Sansion
Established in 2005, Sansion Power Electric comprises technical experts with over 20 years of experience in R&D, manufacturing, and marketing of power electrical testing products. Our solutions are widely applied across power electric, railroad, energy conservation and environment protection, water conservancy, petrochemical industry, aerospace, and other sectors.
Sansion Power Electric includes R&D department, instruments manufacturing workshop, HV workshop, sample exhibition room, HV testing laboratory, quality control department, general office, sales departments, and information office. We currently employ over 80 staff members, including 20 technical engineers.
We have obtained ISO9001 quality system certification, and all products strictly conform to international IEC and Chinese state standards.
FAQ
- Is your company a sales company or a manufacturer? Sansion Power Electric Co., Ltd. is an industrial and trade enterprise with its own factory, self-produced and self-sold. Founded in 2005, we have twenty years of production experience with reliable production lines, test rooms, and R&D centers.
- Are goods in stock, can they be customized, and what is the delivery time? Goods are made to order according to customer requirements using the latest technology. Delivery time is typically within 10 working days.
- Is the quality guaranteed? We use imported components and conduct three quality inspections before shipment. Export products are packed in non-fumigation wooden boxes.
- What are the after-sales terms? We offer free consulting service, one year warranty, and support through email communication, video calls, and on-site technical assistance to resolve after-sales problems promptly.
- What are the cooperative countries or regions? Products exported to United States, France, Brazil, Australia, Spain, Portugal, Oman, Russia, Netherlands, Indonesia, Bangladesh, Saudi Arabia, Chile, Colombia, Panama, Malaysia and other countries.
